5.2.4 Counting commissioning
Edit multistep program on programming page (setting number of work piece is over 1,
single step is excluded), press “Start”, depress pedal to dry running when X, Y axis are
in position (note Y axis position and pressure), observe whether counting has
increased; if no change occurs, check whether Start signal wires are correctly and
reliably connected to the system.
5.2.5 Retreat commissioning
Edit single-step program on programming page (retreat value is 5mm), press “Start”,
depress pedal to dry running when X-axis, Y-axis are in position (note Y-axis position
and pressure).observe whether there is retreat and the retreat sequence is correct. If
problem is found, check whether Press signal wire (IN2) is correctly and reliably
connected to the system, and whether yield distance (Dx value) set is correct and
reasonable.
5.2.6 Teach function commissioning
When the above procedures are finished, roughly correct actual position of X and Y
axis by teach function. Edit single step program to carry out actual processing,
measure dimension of the processed work piece, then correct scale error by teach
function.
