ES4440.2 Compact Failure Simulation Module - User’s Guide 41
ETAS Pin Assignment
U LOAD17 ECU17
V LOAD18 ECU18
W LOAD19 ECU19
Y LOAD20 ECU20
Z LOAD21 ECU21
a LOAD22 ECU22
b LOAD23 ECU23
c LOAD24 ECU24
d LOAD25 ECU25
e LOAD26 ECU26
f LOAD27 ECU27
g LOAD28 ECU28
h LOAD29 ECU29
j LOAD30 ECU30
k LOAD31 ECU31
l LOAD32 ECU32
m LOAD33 ECU33
n LOAD34 ECU34
p LOAD35 ECU35
r LOAD36 ECU36
s LOAD37 ECU37
t LOAD38 ECU38
u LOAD39 ECU39
v LOAD40 ECU40
w LOAD41 ECU41
y LOAD42 ECU42
Pin Signal Internally Connected to Connector
”ECU CH43-CH63” - Pin:
A LOAD43 ECU43
B LOAD44 ECU44
C LOAD45 ECU45
D LOAD46 ECU46
E LOAD47 ECU47
F LOAD48 ECU48
Tab. 3-10 ”LOAD CH43-CH63” Pin Assignment
Pin Signal Internally Connected to Connector
”ECU CH0-CH42” - Pin:
Tab. 3-9 ”LOAD CH0-CH42” Pin Assignment (Forts.)
