ES4440.2 Compact Failure Simulation Module - User’s Guide36
Pin Assignment ETAS
3.8 ”ECU CH0-CH42” / ”ECU CH43-CH63” Connector
The 64 high-current channels of the ECU are connected via these two connec-
tors.
Type: ITT Cannon CA02COM-E28A51P-B-01 (male)
Counterpart: ITT Cannon CA06COM-E28A51S-B-01 (female)
Fig. 3-7 ”ECU CH0-CH42” and ”ECU CH43-CH63” Pin Assignments
N LOAD12 ECU12
P LOAD13 ECU13
R LOAD14 ECU14
S LOAD15 ECU15
T**
* The pins T of „LOAD HV“ and „ECU HV“ are directly connected with each
other
Pin Signal Internally Connected to Connector
”LOAD CH0-CH42” - Pin:
A ECU0 LOAD0
B ECU1 LOAD1
C ECU2 LOAD2
D ECU3 LOAD3
E ECU4 LOAD4
F ECU5 LOAD5
Tab. 3-7 ”ECU CH0-CH42” Pin Assignment
Pin Signal Internally Connected to Connector
”ECU HV” - Pin:
Tab. 3-6 ”LOAD HV” Pin Assignment (Forts.)
D ECBA
G J KF H L
N R SM P T U
W Z aV Y b c
e g hd f j k
m p rl n s
w yvut
