ES4440.2 Compact Failure Simulation Module - User’s Guide 37
ETAS Pin Assignment
G ECU6 LOAD6
H ECU7 LOAD7
J ECU8 LOAD8
K ECU9 LOAD9
L ECU10 LOAD10
M ECU11 LOAD11
N ECU12 LOAD12
P ECU13 LOAD13
R ECU14 LOAD14
S ECU15 LOAD15
T ECU16 LOAD16
U ECU17 LOAD17
V ECU18 LOAD18
W ECU19 LOAD19
Y ECU20 LOAD20
Z ECU21 LOAD21
a ECU22 LOAD22
b ECU23 LOAD23
c ECU24 LOAD24
d ECU25 LOAD25
e ECU26 LOAD26
f ECU27 LOAD27
g ECU28 LOAD28
h ECU29 LOAD29
j ECU30 LOAD30
k ECU31 LOAD31
l ECU32 LOAD32
m ECU33 LOAD33
n ECU34 LOAD34
p ECU35 LOAD35
r ECU36 LOAD36
s ECU37 LOAD37
t ECU38 LOAD38
u ECU39 LOAD39
Pin Signal Internally Connected to Connector
”LOAD CH0-CH42” - Pin:
Tab. 3-7 ”ECU CH0-CH42” Pin Assignment (Forts.)
