ES4440.2 Compact Failure Simulation Module - User’s Guide38
Pin Assignment ETAS
v ECU40 LOAD40
w ECU41 LOAD41
y ECU42 LOAD42
Pin Signal Internally Connected to Connector
”LOAD CH43-CH63” - Pin:
A ECU43 LOAD43
B ECU44 LOAD44
C ECU45 LOAD45
D ECU46 LOAD46
E ECU47 LOAD47
F ECU48 LOAD48
G ECU49 LOAD49
H ECU50 LOAD50
J ECU51 LOAD51
K ECU52 LOAD52
L ECU53 LOAD53
M ECU54 LOAD54
N ECU55 LOAD55
P ECU56 LOAD56
R ECU57 LOAD57
S ECU58 LOAD58
T ECU59 LOAD59
U ECU60 * LOAD60
V ECU61 * LOAD61
W ECU62 * LOAD62
Y ECU63 * LOAD63
Z Shield 1
(shielding for
ECU60/ECU61)
*
Shield 1
a Shield 2
(shielding for
ECU62/ECU63)
*
Shield 2
b n.c. n.c.
c n.c. n.c.
d n.c. n.c.
Tab. 3-8 ”ECU CH43-CH63” Pin Assignment
Pin Signal Internally Connected to Connector
”LOAD CH0-CH42” - Pin:
Tab. 3-7 ”ECU CH0-CH42” Pin Assignment (Forts.)
