ES4440.2 Compact Failure Simulation Module - User’s Guide 43
ETAS Pin Assignment
u n.c. n.c.
v n.c. n.c.
w n.c. n.c.
y n.c. n.c.
* The lines of the signals ”LOAD60”, ”LOAD61” (pins U,V) and ”LOAD62”,
”LOAD63” (pins W,Y) are routed to ”ECU CH43-CH63” as ”twisted pairs”.
Together with the two ”Shield” lines (pins Z and a), these are thus suitable to
be used as CAN lines, but can also be used as normal channels.
Pin Signal Internally Connected to Connector
”ECU CH43-CH63” - Pin:
Tab. 3-10 ”LOAD CH43-CH63” Pin Assignment (Forts.)
