ES4440.2 Compact Failure Simulation Module - User’s Guide 51
ETAS Technical Data
Fuses
The hardware revisions 1.10 and 1.11 have different fuse specifications from
those described above. The table below contains the correct specification for
these revisions:
Electrical Data
Mechanical Data
E1, E2, E3* 20 A, 32 V in acc. with ISO 8820-3 (e.g. Pudenz, FKS series)
E4* 3 A, 32 V in acc. with ISO 8820-3 (e.g. Pudenz, FKS series)
E5* 10 A, 80 V in acc. with ISO 8820-3 (e.g. Pudenz, FKS series)
Mains circuit
breaker **
2 x 1.6 AH slow-blow, 250 V, glass fuse 5x20 (IEC60127-2/3)
* For information on the position of the fuses see "To change fuses"
on page 29
** see "Changing the Mains Fuses" on page 29
E1, E3, E4 20 A, 32 V in acc. with ISO 8820-3 (e.g. Pudenz, FKS series)
E2 3 A, 32 V in acc. with ISO 8820-3 (e.g. Pudenz, FKS series)
E5 10 A, 80 V in acc. with ISO 8820-3 (e.g. Pudenz, FKS series)
Note
The hardware revision number is on the back of the ES4440.1.
Input voltage (mains frequency) 100 - 240 VAC (50 Hz /60 Hz)
Power input 70 W
Overvoltage category II
Pollution degree 2
Height of the front panel 3 U
Width of the front panel 19”
Depth (incl. connectors) 455 mm
Weight 14 kg/31 lbs
