ETC P-ACP User Manual

3 Programming 32
100 - 120 VAC Racks
Module Type Description of Purpose Compatible Loads
AFM required in empty dimmer slots not applicable
CC15 and CC20
direct connection from line lug to load lugs
protected by 15 or 20 amp circuit breaker
constant loads such as power supplies
or other constant-on loads
D15 and D20
D15E and D20E
standard 15 or 20 amp dimmer
enhanced dimmer with 500s rise time
Incandescent, 2 and 4 wire fluorescent,
magnetic low voltage, neon, cold
cathode (CC) and non-dim
D15F and D20F 15 and 20 amp fluorescent dimmers
3 wire dimmable electronic fluorescent
ballast
D15FB and D20FB
15 and 20 amp fluorescent dimmers with integrated
battery.
2 wire dimmable electronic fluorescent
ballast with battery pack
R15 and R20 15 or 20 amp, level activated mechanical relay any switched load
ELV10 10 amp reverse phase module electronic low voltage loads
277 VAC Racks
Module Type Description of Purpose Compatible Loads
AFM required in empty dimmer slots not applicable
ACC15 and ACC20
direct connection from line lug to load lugs
protected by 15 or 20 amp circuit breaker
constant loads such as power supplies
or other constant-on loads
AD15 and AD20
standard 15 or 20 amp dimmer
enhanced dimmer with 500s rise time
Incandescent, 2 and 4 wire fluorescent,
magnetic low voltage, neon, cold
cathode (CC) and non-dim
AD15F and AD20F 15 and 20 amp fluorescent dimmer
3 wire dimmable electronic fluorescent
ballast / 2 wire ballast with battery pack
AD15B and AD20FB
15 and 20 amp fluorescent dimmers with integrated
battery.
2 wire dimmable electronic fluorescent
ballast with battery pack
AR15 and AR20 15 or 20 amp, level activated mechanical relay any switched load
AELV5 5 amp reverse phase module electronic low voltage loads
230 and 240 VAC Racks
Module Type Description Compatible Loads
AFM required in empty dimmer slots not applicable
ECC15 and ECC25 15 or 25 amp circuit breaker
constant loads such as power supplies
or other constant-on loads
ED15
ED15E and ED25E
ED15N
ED15NE and ED25NE
ED25NS
standard 15 amp dimmer
15 or 25 amp enhanced 400s rise time dimmer
neutral disconnect dimmer
enhanced 400s neutral disconnect dimmer
25 amp 400s neutral disconnect (single module)
Incandescent, 2 and 4 wire fluorescent,
magnetic low voltage, neon, cold
cathode (CC) and non-dim
ED15RE and ED25RE
ED15RS and ED25RS
ED25S
15 or 25 amp RCD module 400s rise time dimmer
15 or 25 amp RCD module 225s rise time dimmer
25 amp 400s rise time (single) dimmer module
3 wire dimmable electronic fluorescent
ballast
ER15 and ER25 15 or 25 amp level activated mechanical relay any switched load
HD15
HD15F
240 VAC 15 amp dimmer module
240 VAC 15 amp fluorescent dimmer module
Incandescent, fluorescent, magnetic
low voltage, neon, cold cathode (CC)
and non-dim
HCC15 240 VAC 15 amp circuit breaker
constant loads such as power supplies
or other constant-on loads
HELV5 240 VAC 5 amp reverse phase module electronic low voltage loads
HR15 240 VAC 15 amp, level activated mechanical relay any switched load
