Appendix B
Dimmer Specifications
Unison DRd Rack Compatible Modules
120 VAC Dimmer Modules
Module
Type
Description Part Number
Module Weight
(lbs/kg)
AFM Air Flow Module 7083A1072 1.3 lbs / .59 kgs
CC15 Dual 15A Constant Circuit Breaker Module 7083A1021 2.1 lbs / 1.0 kgs
CC20 Dual 20A Constant Circuit Breaker Module 7083A1025 2.2 lbs / 1.0 kgs
D15 Dual 15A, 1.8KW, 350µS Dimmer Module 7083A1018 5 lbs / 2.3 kgs
D15E Dual 15A, 1.8KW, 500µS Dimmer Module 7083A1019 5 lbs / 2.3 kgs
D15F Single 15A, Fluorescent Dimmer Module 7083A1020 2.4 lbs / 1.1 kgs
D15FB Single 15A, Fluorescent / Battery Dimmer Module 7183A1073 2.4 lbs / 1.1 kgs
D20 Dual 20A, 2.4KW, 350µS Dimmer Module 7083A1022 5 lbs / 2.3 kgs
D20E Dual 20A, 2.4KW, 500µS Dimmer Module 7083A1023 5 lbs / 2.3 kgs
D20F Single 20A, 2.4KW Fluorescent Dimmer Module 7083A1024 2.4 lbs / 1.1 kgs
D20FB Single 20A, Fluorescent / Battery Dimmer Module 7183A1074 2.4 lbs / 1.1 kgs
ELV10 Reverse Phase 10A at 120 VAC, Dimmer Module 7183A1017 2.6 lbs / 1.2 kgs
R15 Dual 15A at 120 VAC Relay Module 7083A1084 2.6 lbs / 1.2 kgs
R20 Dual 20A at 120 VAC, Relay Module 7083A1085 2.6 lbs / 1.2 kgs
230 VAC Dimmer Modules
Module
Type
Description Part Number
Module Weight
(lbs/kg)
AFM Air Flow Module 7083A1072 1.3 lbs / .59 kgs
ECC15 Dual 15A, 3KW Constant Circuit Module 7070A1046 2.7 lbs / 1.2 kgs
ECC25 Dual 25A, 5KW Constant Circuit Module 7070A1047 2.5 lbs / 1.1 kgs
ED6 Dual 6A, 1.3KW 400µS Dimmer Module 7183A1085 5.5 lbs / 2.5 kgs
ED6N Dual 6A, 1.3KW 400µS Neutral Disconnect Dimmer Module 7183A1079 5.6 lbs / 2.5 kgs
ED10 Dual 10A, 2.3KW 400µS Dimmer Module 7183A1086 5.5 lbs / 2.5 kgs
ED10N Dual 10A, 2.3KW 400µS Neutral Disconnect Dimmer Module 5.6 lbs / 2.5 kgs
ED15 Dual 15A, 3KW, 225µS Dimmer Module 7083A1035 1.3 lbs / .59 kgs
ED15E Dual 15A, 3KW, 400µS Dimmer Module 7083A1032 5 lbs / 2.3 kgs
ED15N Dual 15A, 3KW, 225µS Neutral Disconnect Dimmer Module 7083A1041 5.6 lbs / 2.5 kgs
ED15NE Dual 15A, 3KW, 400µS Neutral Disconnect Dimmer Module 7083A1042 5.6 lbs / 2.5 kgs
ED15R Dual 15A, 3KW, 225µS RCD Module 7083A1045 5 lbs / 2.3 kgs
ED15RE Single 15A, 3KW, 400μS RCD Module 7083A1046 5 lbs / 2.3 kgs
ED25 Single 25A, 400µS Dimmer Module 7083A1033 5.5 lbs / 2.5 kgs
ED25E Single 25A, 5KW, 600µS Dimmer Module 7083A1034 5.5 lbs / 2.5 kgs
ED25NE Single 25A, 5KW, 600µS, Neutral Disconnect Dimmer Module 7083A1044 5 lbs / 2.3 kgs
ED25N Single 25A, 5KW, 400µS Neutral Disconnect Dimmer Module 7083A1043 5.5 lbs / 2.5 kgs
