ETC P-ACP User Manual

B Unison DRd Rack Compatible Modules 86
Dimmer Modes
Normal Mode
Property Units Default 120V
Default
230/240 VAC
Default 277V
Curve not applicable Mod-Square Mod-Square Mod-Square
Voltage Regulation On / Off On On On
Pre-Heat On / Off Off Off Off
Dynamic Preheat Seconds 0sec / Off 0sec / Off 0sec / Off
Min Scale Volts 6V 12V 14V
Max Scale Volts 118V 230V 277V
Transformer Mode On/Off Off Off Off
Threshold % Control 1% (>0%) 1% (>0%) 1% (>0%)
“Normal Mode” typically applies to standard dimmer modules.
Dimmer Doubled Mode
Property Units Default 120V
Default
230/240V
Default 277V
Curve NA Mod-Square not applicable not applicable
Voltage Regulation On / Off On not applicable not applicable
Pre-Heat On / Off Off not applicable not applicable
Dynamic Preheat seconds 0sec / Off not applicable not applicable
Min Scale Volts 6V not applicable not applicable
Max Scale Volts 110V not applicable not applicable
Transformer Mode On / Off not applicable not applicable not applicable
Threshold % Control 1% (>0%) not applicable not applicable
“Dimmer Doubled Mode” applies only to channels using ETC’s Dimmer Doubling™ technology.
Note:
“Dimmer Doubled Mode” does not apply to the DRd12-48 rack or any DRd rack
with an operating voltage of 230, 240, or 277 VAC.
Switched Mode
Property Units Default 120V Default 230V Default 277V
Curve not applicable Linear Linear Linear
Voltage Regulation On / Off Off Off Off
Pre-Heat On / Off Off Off Off
Dynamic Preheat seconds 0sec / Off 0sec / Off 0sec / Off
Min Scale Volts 120 =Max 230 =Max 277 =Max
Max Scale Volts 120 230 277
Transformer Mode On / Off On On On
Threshold Control 50 50 50
“Switched Mode” is typically the mode of operation for relay modules.
