ETC P-ACP User Manual

B Unison DRd Rack Compatible Modules 88
Off Mode
Property Units Default 120V Default 230V Default 277V
Curve not applicable Linear Linear Linear
Voltage Regulation On / Off Off Off Off
Pre-Heat On / Off Off Off Off
Dynamic Preheat seconds 0sec / Off 0sec / Off 0sec / Off
Min Scale Volts 0 0 0
Max Scale Volts 0 0 0
Transformer Mode On / Off Off Off Off
Threshold Control 0 0 0
Reverse Phase Mode
Property Units Default 120V Default 230V Default 277V
Curve not applicable Mod-Square NA Mod-Square
Voltage Regulation On / Off On NA On
Pre-Heat On / Off Off NA Off
Dynamic Preheat seconds 0sec / Off NA 0sec / Off
Min Scale Volts 6V NA 14V
Max Scale Volts 118V NA 277V
Transformer Mode On / Off Off NA Off
Threshold % Control 1% (>0%) NA 1% (>0%)
“Reverse Phase Mode” is used only with the RPC module.
Note:
“Reverse Phase Mode” is selectable only when the module type is the ELV10,
AELV5, or HELV5 electronic low voltage module. The electronic low voltage
module is not supported for 230 VAC systems.
