Source Four LED Profile
Source Four LED Profile Page 7 of 8 ETC
Channel Assignments in Direct Mode
Plus7 Profile Options
Tungsten and Daylight
Channel
Number
Series 1
Studio HD
Series 1
Lustr+
Series 2
Lustr
Series 2
Daylight HD
Series 2
Tungsten HD
1 Red Red Red Red Red
2 Red Orange White Lime (not used) Red Orange
3 Mint Amber Amber Mint Mint
4 Blue Green Green Blue Blue
5 Indigo Cyan Cyan Indigo Indigo
6 n/a Blue Blue n/a n/a
7 n/a Indigo Indigo n/a n/a
8 Intensity Intensity Intensity Intensity Intensity
9 Strobe Strobe Strobe Strobe Strobe
10 Fan Control Fan Control Fan Control Fan Control Fan Control
Channel
Number
Series 1
Studio HD
Series 1
Lustr+
Series 2
Lustr
Series 2
Daylight HD
Series 2
Tungsten HD
1 Hue (coarse) Hue (coarse) Hue (coarse) Intensity Intensity
2 Hue (fine) Hue (fine) Hue (fine) White Point White Point
3 Saturation Saturation Saturation Tint Tint
4 Intensity Intensity Intensity (not used) (not used)
5 Strobe Strobe Strobe Strobe Strobe
6 Fan Control Fan Control Fan Control Fan Control Fan Control
7 (not used) (not used) (not used) (not used) (not used)
8
Plus7 Control
on/off
Plus7 Control
on/off
Plus7 Control
on/off
Plus7 Control
on/off
Plus7 Control
on/off
9 Red Red Red Red Red
10 Red Orange White Lime (not used) Red Orange
11 Mint Amber Amber Mint Mint
12 Blue Green Green Blue Blue
13 Indigo Cyan Cyan Indigo Indigo
14 (not used) Blue Blue (not used) (not used)
15 (not used) Indigo Indigo (not used) (not used)
DMX
Profile
DMX
Channels
Channel
Assignments
Notes
Studio 3
1 - Intensity
Control of parameters is also enabled from the
luminaire's user interface. No console is required.
2 - Strobe
3 - Fan Control
Direct 3
1 - Intensity
2 - Strobe
3 - Fan Control
