9.7. Connector assignment of Y-distributor
M12x1
max. 45
Ø 14,5
Strapping plug 097645
4-pin, plug
(gure similar)
Y-distributor with connecting
cable 111696 or 112395
Socket
Pin Function
X2.1 U
B
X2.2 OA
X2.3 0V
X2.4 OB
X2.5 RST
Pin Function
X3.1 U
B
X3.2 IA
X3.3 0V
X3.4 IB
X3.5 RST
12
12
097627
45°
15,1
4
85
6
3
12
7
35,1
20,5
1
2
4
5
3
3
4
2
1
5
Mx1
Ø 14,6
Mx1
( )
Y-distributor
097627
Socket
Connector assignment of safety
switch CES-AR (8-pin plug) and
Y-distributor (8-pin socket)
Pin Function
X1.1 IB
X1.2 U
B
X1.3 OA
X1.4 OB
X1.5 OUT
X1.6 IA
X1.7 0V
X1.8 RST
M 12 x1
44
45 41
15
M 12 x1
15 15
M 12 x1
33
A
B
4
8
5
6
3
1
2
7
1
2
4
5
3
3
4
2
1
5
Length l
Order no.
Length
l [mm]
111696 200
112395 1,000
Pin Function
X2.1 U
B
X2.2 OA
X2.3 0V
X2.4 OB
X2.5 RST
Pin Function
X3.1 U
B
X3.2 IA
X3.3 0V
X3.4 IB
X3.5 RST
Pin
Pin Socket
Socket
