12.2.3. Typical actuating range
(only in combination with actuator CES-A-BBA)
X
25
15
20
10
5
20
25
30
5
10
15
-30
30
-30
25
20
15
10
5
Y
Z
For a side approach direction for the actuator and safety switch, a minimum
distance of s = 4mm must be maintained so that the actuating range of the
side lobes is not entered.
Figure 6: Typical actuating range
