2.3 PRISMA SERIE:
PV – PV/AF MODELS
Vertical units with upper air outlet and bottom (PV) or frontal
(PV/AF) air intake, to be installed on the wall (PV) or on the
floor (both models, but with a set of feet in white RAL 9003
for PV model).
• grilles can be adjusted in all four directions and are made
of heat-resistant ABS
• models equipped with auxiliary drain pan
• 2 pipe systems: 2 or 3 row coils; on 2 row coil units an
electric heater can also be mounted
• 4 pipe systems: additional 1 row coil can be added to
units with a 2 or 3 row coil
• direct expansion system: 3 row direct expansion coil
• standard colour: white casing (RAL 9003), with white
grilles and access doors (RAL 9016)
2.4 PRISMA SERIE:
PH – PH/AF
MODELS
Horizontal units for ceiling installation with frontal air discharge
and rear (PH) or bottom (PH/AF) air intake.
Designed for heating only.
• grilles can be adjusted in all four directions and are made
of heat-resistant ABS
• 2 pipe systems: 2 or 3 row coils; in 2 row coil units an
electric heater can also be mounted
• standard colour: white casing (RAL 9003) with white
grilles and access doors (RAL 9016)
U
D
H
I
F
G
B
