6. REGULATING VALVES
6.1 ON/OFF VALVES: 3-WAY WITH 4 WATER CONNECTIONS (H3A2-H3B2) OR 2-WAY (H2A2-
H2B2), 1/2”-3/4”, 230V, FOR 2 OR 4 PIPE SYSTEMS
The ON/OFF 3-way regulating valves with bypass and 2-way regulating valves are provided with thermoelectric actuator and
connection tubes. The direct water flow is closed by not supplying power to the actuator.
They are suitable for fan coils size 110÷328 and available also with 24V~ (H3B0, H2B0, H3A0, H2A0).
6.2 MODULATING VALVES: 3-WAY WITH 4 WATER CONNECTIONS (J3AM-J3BM) OR 2-WAY
(J2AM-J2BM), 1/2”-3/4”, 24V, FOR 2 OR 4 PIPE SYSTEMS
The modulating 3-way regulating valves with bypass and 2- way regulating valves are provided with modulating actuator
and connection tubes. The direct water flow is closed by not giving the 0-10V signal to the actuator.
They are suitable for fan coils size 110÷328.
VALVES’ TECHNICAL FEATURES
Nominal pressure PN16
Cod.: H2A2, H3A2, J2AM, J3AM, H2B2, H3B2, J2BM, J3BM,
H3B0, H2B0, H3A0, H2A0
Fluid
Hot or cold water for HVAC
system, according to VDI stan
-
dard quality or equivalent
Cod.: H2A2, H3A2, J2AM, J3AM, H2B2, H3B2, J2BM, J3BM,
H3B0, H2B0, H3A0, H2A0
Connection
1/2” GM
3/4” GM
Cod.: H2A2, H3A2, J2AM, J3AM, H3A0, H2A0
Cod.: H2B2, H3B2, J2BM, J3BM, H3B0, H2B0
Max close-off pressure
150kPa
200kPa
250kPa
300kPa
Cod.: J2BM, J3BM
Cod.: H2B2, H3B2, H3B0, H2B0
Cod.: J2AM, J3AM
Cod.: H2A2, H3A2, H3A0, H2A0
Kvs
1,6
1,7
2,5
2,6
Cod.: H2A2, H3A2, H3A0, H2A0
Cod.: J2AM, J3AM
Cod.: H2B2, H3B2, J3BM, H3B0, H2B0
Cod.: J2BM
Material Brass
Cod.: H2A2, H3A2, J2AM, J3AM, H2B2, H3B2, J2BM, J3BM,
H3B0, H2B0, H3A0, H2A0
Flow temperature limit
2÷110 °C
2÷120 °C
Cod.: J2AM, J3AM, J2BM, J3BM
Cod.: H3A2, H2A2, H2B2, H3B2, H3B0, H2B0, H3A0, H2A0
Room temperature limit 2÷50 °C
Cod.: H2A2, H3A2, J2AM, J3AM, H2B2, H3B2, J2BM, J3BM,
H3B0, H2B0, H3A0, H2A0
Actuator
On/Off
Cod.: H2A2, H3A2, J2A2, J3A2, H2B2, H3B2, H3B0, H2B0,
H3A0, H2A0
Cod.: J2AM, J3AM, J2BM, J3BM
Modulating
Voltage supply
230V~ ±15% 50/60 Hz
24V ~ ±15% 50/60 Hz
Cod.: H2A2, H3A2, H2B2, H3B2
Cod.: J2AM, J3AM, J2BM, J3BM, H3B0, H2B0, H3A0, H2A0
Control signal 0÷10 Vcc Cod.: J2AM, J3AM, J2BM, J3BM
Absorption
3 VA
Cod.: H2A2, H3A2, H2B2, H3B2, J2BM, J3BM, H3B0, H2B0,
H3A0, H2A0
Cod.: J2AM, J3AM
2,5 VA
Opening time (20 °C) ~ 200s Cod.: H2A2, H3A2, H2B2, H3B2, H3B0, H2B0, H3A0, H2A0
Closing time (20 °C) ~ 300s
Cod.: H2A2, H3A2, H2B2, H3B2, H3B0, H2B0, H3A0, H2A0,
H3B0, H2B0, H3A0, H2A0
Protection grade
IP43 (EN 60529)
Cod.: H2A2, H3A2, J2A2, J3A2, H2B2, H3B2, H3B0, H2B0,
H3A0, H2A0
Cod.: J2AM, J3AM, J2BM, J3BM
IP43
