5. ELECTRICAL ACCESORIES
5.1 ELECTRIC BOX CBL10
Self-extinguishing plastic box (class V0), which contains a 12 pole terminal board and a voltage transformer (230/24 V~ 10 VA),
for the electrical connection of the modulating valves. It is supplied as standard when the regulators CER10/B e CER30/B are
requested.
5.2 ELECTRIC BOX CBL20
Self-extinguishing plastic box (class V0), which contains a 12 pole terminal board and a power relay card (230 V~):
this card is requested either when an electric heater is mounted on the fancoil unit or to control the fan speeds in Master/
Slave configuration. It can be combined with the following regulators: CMR00, CER00 and CER20.
5.3 ELECTRIC BOX CBL30
Self-extinguishing plastic box (class V0), which contains a 12 pole terminal board, a voltage transformer (230/24 V~ 10 VA)
for the electrical connection of the modulating valves and/or 24 V~ controls, a power relay card (24 V~), which is requested
to control the fan speeds in Master/Slave configuration.
It can be combined with the following regulators: CER11, CER31, CER00 and CER20 (with power supply 24 V).
5.4 ELECTRIC HEATER - KREL
Electric heater supplied with 2 safety thermostats, one with automatic resetting and the other one with manual resetting
(in accordance with LVD 2006/95/CE, EMC 2004/108/CE Directives), and a power relay card (CBL20).
Table A
COMPATIBILITY
Model
SV
SV/AF
SH
SH/AF
CV
CV/AF
CH
CH/AF
PV
PV/AF
PH
PH/AF
SVR
CVR
Type of coil
B2
• • • • • • •
B3
• • • •
B4
• •
BE3
• • • •
Table B
SIZE 110 112 114 216 218 220 222 224 226 328
Power (kW)
0,5 1,0 1,5 2,0 2,25 2,5 2,5 3,0 3,0 3,5
The table A shows the availability of the electric heater for the different models, in relation to the coil mounted on the unit.
The table B shows the power of the electric heater for each unit size. An electric heater with a lower power rating than shown
can always be installed.
