Setup Cards
28 3GS User Guide
Setup Cards
3GS has a capacity of up to 10,000 access cards. This menu will set up the cards for use with the system.
✍ The 3GS panel menus for cards are similar to those of 3GS+ Software. The card settings
entered into the panel can be uploaded to the PC and vice versa. Using 3GS+ to change
access cards settings is recommended.
Cards .. Assign
To pass cards into the 3GS system, they must be
given a card ID between 1 and 9999.
This menu allows you to assign IDs to cards in 2
ways:
l Select. Batches of cards with pre-coded
numbers of between 1 and 9999 can be passed
directly into the system and given
corresponding system IDs. the first card of the
batch becomes Card ID 1, the second becomes
Card ID 2, etc.
In effect, this gives you 1-to-1 mapping,
automatically assigning IDs to cards.
l Learn. The card to be passed is of unknown
origin and the pre-encoded number is not
known. In this case the card is presented at a
card reader, assigned to a system door, and
then given a system ID.
You will be prompted if the ID has already
been assigned, in which case you can over-
write the existing card, or choose the next available ID.
UNSET HELP
HALF
HELP
UNSET
UNSET
UNSET
SET UP CARDS
CARD 1 -> NOT ASSIGNED
CARD 1
Door 1
FROM CARD 1
Card 1
Identify the door at which you are
setting up the card. This frees all
other doors on the system for
normal use
Select the beginning and end of
the range of pre-programmed
cards to be mapped into the system.
_
By default, the display is
Card 1 of this range has now been given
ID no. 1, Card 2: Id no. 2 etc.
ENTER CARD ID 1
CARD 1
Card 9999
_
#
