Passing and Voiding Cards
30 3GS User Guide
Passing and Voiding Cards
Once a Card ID has been assigned, the card can then be passed into the system.
Card Range
Enter the range of cards to be passed, from 1 to 9999. To pass a single card,
enter the card number and press the key twice.
Once the card(s) has been passed, you will be prompted for the Access level
for this/these cards.
Change Access Level ?
An Access level is a combination of a limited time period and a group of
doors, so that once applied to a card, it will limit the card user to having
access to certain doors at certain times only. Up to 250 Access levels are
programmed by the installer, who will indicate which levels should be
assigned to which cards. When you have assigned an Access level, you are
prompted for the Visitor Level.
Change Visitor Level ?
The Visitor Level is used to program temporary cards, which will only be valid for a certain period of time
(between a given Start Date and End Date). The system allows for up to 250 different Visitor levels, which
are programmed by the installer. Once assigned, you are then prompted for a Function level.
Change Function Level ?
Function levels give the user the ability to set and unset an Area by presenting a card to a reader outside the
Area entrance door. A Function level will give a card 3 extra capabilities: to unset an area from the outside,
to unset an area from inside, and to set an area once you have left (by swiping your card at a reader near the
exit door). Up to 250 Function levels are programmed by the installer. When you have assigned a function
level, you are prompted to change the PIN code requirement for the card.
✍ Please consult your installer on the correct procedure for setting/unsetting the system
using your card.
Change Access Levels ?
Not Assigned
Enter Access Level No. 1
YES
NO
current
assignment
#
#
/
Change Visitor Level ?
Not Assigned
Enter Visitor Level No. 1
YES
NO
current
assignment
#
#
/
