EVCO S.p.A. c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 14 of 90
6 LIST OF THE PAGES
This chapter describes the main pages and the menus in the application. As described above, the general menu is divided up into four
levels of submenu: user, maintenance operator, installation operator, and configuration.
The menu is structured as follows:
Menu Function of the menu
General Menu
RTC Menu
Alarm Menu
User Menu (level 1)
Maintenance Menu
(Level 2)
Operation
Manual
Calibration
Input/Output
Installer Menu
(Level 3)
Compressors
Regulation
Fans
Defrost
Pumps
Antifreeze
Free-cooling
Safety devices of the equipment
Modbus
Various parameters
Manufacturer Menu
(Level 4)
Configuration
Hardware Configuration
EVDRIVE03 (circuit 1, circuit 2)
6.1 Passwords
Each menu is assigned a level that represents the accessibility to the different menus.
A password is assigned to each level that grants access to the different functions offered by the menu; after having entered the correct
password, the protected functions become accessible. The entry of the correct password has two consequences:
• unlocking of the relative level;
• unlocking of its sub levels.
All the level passwords may be modified from the same level or higher levels. For example, from the manufacturer level you can
change all the passwords of the lower levels using the appropriate page.
The range of values that can be set for a password is -999/9999
Once four minutes have elapsed without having pressed any key, the password expires and you have to reset it.
