9 9 Coil temperature Circuit 2
10 10 Compressor discharge temperature Circuit 1
11 11 Compressor discharge temperature Circuit 2
12 12 Remote temperature (Storage tank)
13 - Condensation pressure Circuit 1 (4-20mA)
14 - Condensation pressure Circuit 1 (0-5V)
15 - Condensation pressure Circuit 2 (4-20mA)
16 - Condensation pressure Circuit 2 (0-5V)
17 - Evaporation pressure Circuit 1 (4-20mA)
18 - Evaporation pressure Circuit 1 (0-5V)
19 - Evaporation pressure Circuit 2 (4-20mA)
20 - Evaporation pressure Circuit 2 (0-5V)
21 - Single pressure Circuit 1 (4-20mA)
22 - Single pressure Circuit 1 (0-5V)
23 - Single pressure Circuit 2 (4-20mA)
24 - Single pressure Circuit 2 (0-5V)
25-26 13-14 Summer/Winter NC-NO
27-28 15-16 On/Off NC-NO
29-30 17-18 Change setpoint NC-NO
31-32 19-20 Heat sink exchanger flow switch NC-NO
33-34 21-22 Heat source exchanger flow switch NC-NO
35-36 23-24 Pump 1 thermal switch heat sink exchanger NC-NO
37-38 25-26 Pump 2 thermal switch heat sink exchanger NC-NO
39-40 27-28 Pump 1 thermal switch heat source exchanger NC-NO
41-42 29-30 Pump 2 thermal switch heat source exchanger NC-NO
43-44 31-32 Free-cooling external fan thermal switch NC-NO
45-46 33-34 High-pressure Circuit 1 NC-NO
47-48 35-36 Low-pressure Circuit 1 NC-NO
49-50 37-38 Compressor thermal switch 1 NC-NO
51-52 39-40 Compressor thermal switch 2 NC-NO
53-54 41-42 Compressor thermal switch 3 NC-NO
55-56 43-44 Fan thermal switch Circuit 1 NC-NO
57-58 45-46 High-pressure Circuit 2 NC-NO
59-60 47-48 Low-pressure Circuit 2 NC-NO
61-62 49-50 Compressor thermal switch 4 NC-NO
63-64 51-52 Compressor thermal switch 5 NC-NO
65-66 53-54 Compressor thermal switch 6 NC-NO
67-68 55-56 Fan thermal switch Circuit 2 NC-NO
7.3 DI Configuration
Below is the table of values for configuration of the positions of the digital inputs of the controller and the expansion.
HB01-HB14 Parameters nano+ Digital Input
0 Disabled
1-2 Summer/Winter NC-NO
3-4 On/Off NC-NO
5-6 Change setpoint NC-NO
7-8 Heat sink exchanger flow switch NC-NO
9-10 Heat source exchanger flow switch NC-NO
11-12 Pump 1 thermal switch heat sink exchanger NC-NO
13-14 Pump 2 thermal switch heat sink exchanger NC-NO
