page 85 of 90
AC26 Compressor thermal switch #6 A/M Compressor # 6 OFF
AP21 Pump thermal switch #1 A/M Pump # 1 OFF If the single pump switches
off all the compressors and
fans, otherwise it tries to
switch on the other pump
AP22 Pump thermal switch #2 A/M Pump # 2 OFF
AP23 Source pump thermal switch #1 A/M Source pump # 1 OFF If the single pump switches
off all the compressors and
fans, otherwise it tries to
switch on the other pump
AP24 Source pump thermal switch #2 A/M Source pump # 2 OFF
AF21 Fan thermal switch Circuit #1 A/M Fan # 1 OFF
Settable delay
AF22 Fan thermal switch Circuit #2 A/M Fan # 2 OFF
AC01 Compressor operating hours #1 Auto Only shown
AC02 Compressor operating hours #2 Auto Only shown
AC03 Compressor operating hours #3 Auto Only shown
AC04 Compressor operating hours #4 Auto Only shown
AC05 Compressor operating hours #5 Auto Only shown
AC06 Compressor operating hours #6 Auto Only shown
AP01 Pump operating hours #1 Auto Only shown
AP02 Pump operating hours #2 Auto Only shown
AP03 Source pump operating hours #1 Auto Only shown
AP04 Source pump operating hours #2 Auto Only shown
AF01 Fan operating hours Circuit #1 Auto Only shown
AF02 Fan operating hours Circuit #2 Auto Only shown
AL06 Source flowmeter A/M
Compressors OFF
Pump ON for
T-sec.
Settable delay
In manual arrest, pump OFF
AL83 Source anti-freeze Circuit #1 Manu
Circuit compressors OFF and
pump ON for T-sec.
AL84 Source anti-freeze Circuit #2 Manu
Circuit compressors OFF and
pump ON for T -sec.
ERTC RTC down/broken alarm A/M
Blocks management of the
RTC
-
EN01 Expansion communication alarm Auto Only shown Settable delay
EVM1 EVCM Circuit #1 communication alarm Auto
All the compressors of the
circuit OFF
Settable delay
EVM2 EVCM Circuit #2 communication alarm Auto
All the compressors of the
circuit OFF
Settable delay
ES01 External room temperature probe Auto
Inhibits the functions that
use it
ES02 System input temperature probe (FC) Auto
Inhibits the functions that
use it
ES03 Aux remote temperature probe (storage tank) Auto
Inhibits the functions that
use it
ES04 Heat sink exchanger input temperature probe Auto
Number of compressors ON
settable
Settable delay
ES05
Heat sink exchanger output temperature probe
circuit 1
Auto
Number of compressors ON
settable
ES06
Heat source exchanger output temperature
probe circuit 1
Auto
Inhibits the functions that
use it
ES07 Coil temperature probe circuit 1 Auto
Inhibits the functions that
use it
ES08 Condensation pressure probe circuit 1 Auto Fan forcing settable
ES09 Evaporation pressure probe circuit 1 Auto Fan forcing settable
ES10 Single pressure probe circuit 1 Auto Fan forcing settable
