C-PRO NANO HARDWARE MANUAL
Page 28
Type CAN V2.0B
not optoisolated
Physical Layer 2 wires + common, ISO 11898 standard
Baud rate (L max. = 10 m) 20K
Baud rate (L max. = 5 m) 50K
Baud rate (L max. = 2 m) 125K
Baud rate (L max. = 1 m) 500K
Connector Sconnectable terminals
Serial CAN Communication
Note: baud rate can be selected by parameter
Note: The physical level of the CAN consists of a cable with twisted pair (both shielded
and not shielded). The terminator's impedance is 120
Ω
. A second cable with twisted
pairis used for feeding and common (ground)
Buzzer Number
1
LCD Dispay 4 x 20 alfanumeric backlight 1
Buttons 12 Keyboard
Led 9
