Space User Guide Connections
11
Guitar > > Amp1/Amp2 – Mono or Stereo In/Stereo Out
Connect your guitar cable to Input 1 and a cable from Output 1 to one amp and
a second cable from Output 2 to the other amp. Input Level switch (In Lvl) should be
set to GUITAR and Output Level switch (Out Lvl) set to AMP.
If you are using other stompboxes or pedals, it’s best to connect them in front of .
Connect ’s Input 1 to Output 1 of the other pedal. If the other pedal has stereo
outputs, connect its Output 2 to ’s Input 2. If ’s peak LED lights solidly, set
’s In Lvl to LINE.
To Next Page
