Space User Guide Setup
16
Setting Output Levels
Preset output levels can be adjusted in either Play or Preset Mode.
To set output level:
1) Press Left Footswitch to Bypass the Preset.
2) Press and hold the Left Footswitch, the Preset will now be Active.
3) After holding for 1 second the display will show “OUTLVL 0.0dB” (default value).
4) Turn the Encoder to adjust output level from -30 dB to +20 dB.
Note: Levels change in 0.5 dB increments.
Note: Preset output levels must be saved even if there are no other changes to the preset or
the output level will revert to its previous setting the next time the Preset is loaded.
Peak LED
The Peak LED lights to indicate that the input signal level is near clipping. Occasional flashing
is OK. If the Peak LED is lit solidly, reduce the input level either by reducing the signal level
fed to or by setting the rear panel input switch to the Line position. has a soft
clipping circuit that will reduce nasty noises when overloaded.
Signal Present LED
The GREEN LED immediately below the Peak LED lights to indicate that an input signal is
present. If you’re playing and the Signal Present LED doesn’t light, either the input signal level
is too low, you’re input cable has come unplugged or is in Bypass.
