User Guide System Mode
36
System Menu Tree
The system mode is divided into five categories [BYPASS], [AUX SWITCH], [MIDI], [GLOBAL],
and [UTILITY] which are the top-level menu items that appear when entering system mode.
In the following, factory default settings are indicated in (bold)
[BYPASS] – Select Bypass Mode
After entering System Mode, turn the Encoder to select [BYPASS], then press the Encoder to
enter Select Bypass Mode. Turn the Encoder to select either [BYPASS TYPE] or [KILLDRY].
[BYPASS TYPE] – Choose Bypass Type (DSP, RELAY, DSP+FX)
Press the Encoder to select. Turn Encoder to select DSP, Relay or DSP+FX.
When [DSP] is selected, Bypass sends the audio at the DSP’s inputs directly to the
outputs without any effects processing.
When [RELAY] is selected, Bypass employs a pair of relays to “hardwire” the inputs
to the outputs, giving a “true bypass.”
When [DSP+FX] is selected, Bypass sends the audio at the DSP’s inputs directly to
the outputs with the decaying ‘tail’ of the current effect mixed in.
Press the Middle Footswitch once to back-up one level to BYPASS menu.
Press the Middle Footswitch twice to go to the top level System menu.
[KILLDRY] – Kill Dry Audio (NO, YES)
Press the Encoder to select. Turn Encoder to enable/disable KILLDRY.
When KILLDRY is enabled (YES), the dry signal is removed from the output and
only outputs a 100% wet level. KILLDRY is normally enabled when is
connected in your amp’s effects loop. For some of the Presets the Intensity control
acts as a Wet/Dry Mix control. For these Presets, if KILLDRY is YES, the Intensity
control is disabled.
Press the Middle Footswitch once to back-up one level to BYPASS menu.
Press the Middle Footswitch twice to go to the top level System menu.
[AUX SWITCH] – Program Auxiliary Switches
Up to three Auxiliary Switches can be assigned as controls for the Preset
parameters and system control. The three Aux Switches are connected to the rear
panel ¼” stereo phone jack. detects closures by sensing whether the tip, the
ring or both the tip and ring are grounded. Note that you must use a stereo
phone plug when connecting Aux Switches.
To assign the Aux Switches, first press the Encoder to select [AUX SWITCH]. You
will see two fields (split display) of the Billboard display (left/right) showing
Parameter destination and Control source assignments. The Left Footswitch LED is
