FOLDING INSTRUCTIONS
When not in use, the rower can be folded to save space.
You can fold the rower by locating the Ball Head Pin (65) on the Slide Rail (2) and removing it.
Then, take the Slide Rail (2) and move it into a vertical position.
CAUTION: The Seat (38) will glide down when the Slide Rail (2) is raised.
Also, take care to avoid the Rear Stabilizer (4) when moving the Slide Rail (2).
Once the Slide Rail (2) is in the vertical position, re-insert the Ball Head Pin (65) into its slot on
the Slide Rail (2). This locks the rower into the folded position.
CAUTION: The Slide Rail (2) will not stay in the vertical position before the Ball Head Pin (65) is
inserted. Make sure to not let go of it before it is secured, or the Slide Rail (2) may fall.
2
65
65
2
38
38
4
4
