STEP 2
1. Attach the Rear Stabilizer (4) to the Slide Rail (2). Secure using 4 Bolts (81), 4 Spring
Washers (52), and 4 Washers (55) with the provided Allen Wrench (97).
55
81
52
2
4
6 S F
#81 M8*20 4pcs
#52 ID8.5 4pcs
#55 OD16*ID8.5*1.5 4pcs
STEP 3
1. A piece of plywood has been attached to the Main Frame (1) to stabilize it during shipping.
2. Remove the 2 Bolts and 2 Washers using the Allen Wrench (97).
3. The plywood, bolts, and washers are not needed in further assembly and can be recycled.
Packing
Support
Board
6 S F
0SFV
0 : DVKHUSFV
To Next Page
