7700FR/7800FR MultiFrame
7800TR-32x24 Modular Tally Router
Page - 32
Revision 1.2
6.1.2 Performing a Firmware Upgrade through the Card Edge Serial Port
A firmware upgrade can also be performed through the card edge serial port. This takes much longer
than through Ethernet, and will require access to the front of the card by opening the frame door. The
card will also be non-responsive for the duration of the upgrade. See section 3.3.1 for instructions on
connecting the card edge serial port to a PC. Once the terminal program is connected, press ENTER
to get to the “CLI>” Command Line Interface prompt. The current software version can be displayed by
typing “ver” and pressing ENTER.
There is a 3-pin Run/Upgrade header (J13) about 1.5 inches behind the LED display. Make sure the
shunt is placed in the UPGRADE position (on pins 2-3, toward the rear of the card).
Type in the command “reset” and press ENTER. The tally router will reboot. Immediately press
CTRL+X several times to stop the unit from booting again. This should break into the “PPCBOOT>”
prompt. Type the command “upgrade” and press ENTER. You should see the message “upload
product firmware now”. The firmware can now be sent to the tally router using the XMODEM
protocol (checksum mode). This should take about 4 minutes to complete.
When the firmware is finished sending, you should see the message “upload okay”. At this point
enter the command “boot” and press ENTER. The tally router will boot using the newly upgraded
firmware.
Move the shunt on the Run/Upgrade header (J13) back to the RUN position (pins 1-2).
Evertz NAND PPCBoot et.836.3
Evertz PPCBoot 2.3 et.836.3
8313e rev. 2.2, e300c3 rev. 1.0, 167 MHz bus, 333 MHz core
PHY 01 REG 00: 1140 ---- 0143 BCB2 01E1 0000 0064 2001 0000 0300 0000 0000 0000 0000 0000 3000
PHY 01 REG 10: 0000 0001 0000 0000 0000 0000 0000 0000 0400 0000 0000 FFFF 0000 0000 0000 0000
PHY register 18 shadow 7 changed from 0x71E7 to 0xF0E7
PHY register 1c shadow 3 changed from 0x0E00 to 0x0E00
user requested abort
PPCBOOT> upgrade
upload product firmware now
upload okay
PPCBOOT> boot
LOADING PROGRAM SECTIONS
7800TR-32x24
Hardware
Board : 7700TR
Product : 7800TR
Rev : 3
Build : 1
Serial Number : 7550330003
Software
Version : 1.00
Build : 175
Build Date : 2016 Oct 03 11:56:58
