5.1.3.10. Setting the Line 21 Setup
The Line 21 Setup control is used to set whether or not setup is removed from Line 21 of the incoming
composite video signal.
Video
AnalogIn
CompositeIn
Line21Pedestal
Remove
Don’t Remove
Blank
Select Remove to remove setup from line 21 of the incoming video
signal.
Select dontRemove to bypass the removal of line 21 setup.
5.1.3.11. Setting the NTSC Setup Pedestal
The NTSC Setup Pedestal control is used to select whether or not pedestal is removed from the
composite video inputs.
Video
AnalogIn
CompositeIn
ntsc21Pedestal
Remove
Don’t Remove
Select Remove to remove the NTSC pedestal from the input.
Select dontRemove to pass the input through this processing block and
to not remove NTSC Setup Pedestal.
5.1.3.12. Setting the Video Standard
The Standard control enables the user to select the analog video standard.
Video
AnalogIn
CompositeIn
standard
Auto
NTSC
PAL
NTSC – Sets the video standard to NTSC.
PAL – Sets the video standard to PAL.
Auto – In Auto mode, the Genlock reference video standard is used to
determine what standard to use.
5.1.3.13. Setting the Video Level Control
The Video Level control sets the overall video level/gain for the analog video input.
Video
AnalogIn
CompositeIn
videoLevel
-100 to 100
To set the Video Level control, enter a value between -100 to 100 into
the video level field.
