5.1.4.3. Setting the Brightness
The Brightness control allows the user to adjust the brightness of the analog video output.
Video
AnalogOut
CompositeOut
Brightness
-32 to 32
To set the brightness, enter a value between -32 and 32 in the
brightness field. Level -32 corresponds to -15.9 IRE and level 32
corresponds to +15.9 IRE.
5.1.4.4. Setting the Chroma Filter Selection
The chroma information for the encoded video signal may be filtered with a number of filter bandwidths
ranging from 650k to 3.0 MHz. The Chroma Filter control, selects which chroma filter will be applied.
Video
AnalogOut
CompositeOut
chromaFilter
650kHz
1.0MHz
1.3MHz
2.0MHz
3.0MHz
The chroma filter options are listed below:
650kHz: 650k chroma filter applied.
1.0MHz: 1.0 MHz chroma filter applied.
1.3MHz: 1.3 MHz chroma filter applied.
2.0MHz: 2.0 MHz chroma filter applied.
3.0MHz: 3.0 MHz chroma filter applied.
5.1.4.5. Setting the Contrast
The Contrast control allows the user to adjust the contrast of the analog video output.
Video
AnalogOut
CompositeOut
contrast
0 to 768
To set the contrast, enter a value between 0 and 768 into the contrast
field. The default value is 512.
Level 0 corresponds to 0%
Level 512 corresponds to 100%
Level 768 corresponds to150%.
5.1.4.6. Enabling Force Black and White
The Force Black and White control enables the user to force black and white video to be generated
on the analog video output.
Video
AnalogOut
CompositeOut
forceBlackAndWhite
On
Off
Select on to make the composite analog video output black and
white. Select off to enable colour video on the composite output.
