HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
FRONT PANEL OPERATION Revision 0.1 Page 5-55
5.3.1. Setting the IP Address
The IP Address control enables the user to configure the IP address of the HD201x.
"
NOTE: Changes to the HD201x’s IP address are made via the front panel
engineering menu only. When using HD201x firmware revision HD2010A-20100212-
1051.img or earlier
changes done to the units IP address DO NOT become active
until the unit is power-cycled. In firmware revisions HD2010A-20100212-1051.img
or later
, changes to the unit’s IP address done via the front panel become active
immediately.
Misc
network
IP Address
xxx.xxx.xxx.xxx
To set the IP address of the HD201x, use the shaft encoder to toggle
and set the desired IP address fields.
5.3.2. Setting the Default Gateway
The Default Gateway control enables the user to configure the Default Gateway of the HD2014.
"
NOTE: Changes to the HD201x’s IP address are made via the front panel
engineering menu. When using HD201x firmware revision HD2010A-20100212-
1051.img or earlier
changes done to the units IP address DO NOT become active
until the unit is power-cycled. In firmware revisions HD2010A-20100212-1051.img
or later
, changes to the unit’s IP address done via the front panel become active
immediately.
Misc
network
ipDefaultGateway
xxx.xxx.xxx.xxx
To set the gateway of the HD201x, use the shaft encoder to toggle
and set the desired default gateway address.
5.3.3. Setting the Subnet Mask
The Subnet Mask control enables the user to configure the Default Gateway of the HD201x.
"
NOTE: Changes to the HD201x’s IP address are made via the front panel
engineering menu. When using HD201x firmware revision HD2010A-20100212-
1051.img or earlier
changes done to the units IP address DO NOT become active
until the unit is power-cycled. In firmware revisions HD2010A-20100212-1051.img
or later
, changes to the unit’s IP address done via the front panel become active
immediately.
Misc
network
ipNetmask
xxx.xxx.xxx.xxx
To set the subnet mask of the HD201x, use the shaft encoder to
toggle and set the desired default gateway address.
