177
OILING SYSTEM
OIL SUPPLY DIAGRAMS
9
OIL SUPPLY DIAGRAMS
006645
1
3
4
6
2
4
5
5
5
6
6
1.
2.
3.
Oil tank
Oil pick-up/filter
Oil injection pump
4.
5.
6.
Oil distribution manifold
Crankcase oil inlet (port)
Cylinder oil inlet (starboard)
