Evinrude E-TEC E50DPLSCB - Electrical and Ignition: Service Chart

118
ELECTRICAL AND IGNITION
SERVICE CHART
SERVICE CHART
A
F
F
F
F
100 to 115 ft. lbs.
(136 to 156 N·m)
5 to 8 in lbs.
(.6 to .9 N·m)
84 to 106 in lbs.
(9.5 to 12 N·m)
120 to 140 in lbs.
(13.5 to 16 N·m)
60 to 84 in lbs.
(7 to 9.5 N·m)
60 to 84 in lbs.
(7 to 9.5 N·m)
168 to 192 in lbs.
(19 to 21 N·m)
24 to 36 in lbs.
(2.7 to 4 N·m)
24 to 36 in lbs.
(2.7 to 4 N·m)
24 to 36 in lbs.
(2.7 to 4 N·m)
T
A
N
IMPORTANT:
DO NOT lubricate TPS
to throttle shaft surface
A Triple-Guard Grease
B Gasket Sealing Compound
C Adhesive 847
D Moly Lube
E Red Ultra Lock
F Blue Nut Lock
N Starter Bendix Lube
T Liquid Neoprene
002481
