TROUBLESHOOTING
Observation Possible Cause Procedure
ICON system does not
power up.
Network power cable 10 Amp
fuse has failed.
Check network power cable and
connections for damage or short circuit
to ground.
Master power/key switch/
network 3 Amp fuse has failed.
Check master power/key switch cable,
buss cable backbone, all buss cable
extensions and connectors for damage
or short circuit to ground.
ICON Fault Message
displayed. Also see ICON
Fault Messages on p. 23.
Communication error (fault 107)
or failsafe mode (fault 108). ESM
30 Amp fuse has failed.
Check ESM power cable, actuator
cables and all connectors for damage or
short circuit to ground.
Communication errors or faults
(107 or 111) may be caused by
low battery voltage.
Check condition of batteries, battery
connections and/or battery switches.
Check all network connections between
control, ESM and outboard EMM.
Outboard(s) will not shut off
with START/STOP switch.
Outboards must have ICON–
compatible engine management
software installed in the Engine
Management Module (EMM).
If this problem has occurred after
installing an ICON conversion kit, an
authorized Evinrude dealer must install
updated engine management software.
Outboard will not trim/tilt up
and/or down.
Master power/key switch must
be in RUN position.
Outboards must have ICON–
compatible engine management
software installed in the Engine
Management Module (EMM).
Turn master power/key switch to RUN
position.
If this problem has occurred after
installing an ICON conversion kit, an
authorized Evinrude dealer must install
updated engine management software.
NMEA 2000 network/
I-Command gauges are
OFF.
Gateway module is not on.
Check that gateway module LED is ON.
Check power cable and connections
from master power/key switch to
gateway module.
NMEA 2000 buss cable is not
connected or is damaged.
Check NMEA 2000 buss cable
connectors.
Gateway module LED
flashing.
Gateway module is not receiving
data from ICON control network.
Check network connections from
gateway to ICON network hub and buss
cable backbone.
