X EVINRUDE® ICON™ CONCEALED SIDE MOUNT REMOTE CONTROL USER’S GUIDE
ICON FAULT MESSAGES
Fault Message Displayed
on I-Command Gauge Procedure
RPM reduction, ICON fault 107,
see dealer.
Communication Error
Turn master power/key switch OFF and back to RUN position to reset
system. Seek assistance to return to harbor. See dealer.
RPM reduction, ICON fault 108,
see dealer.
ICON System Failsafe Mode
Seek assistance to return to harbor. See dealer.
RPM reduction, ICON fault 109,
see user guide.
Control Hardware Fault
ICON Shutdown - ICON system shifts into NEUTRAL idle if able.
Seek assistance to return to harbor. See dealer.
RPM reduction, ICON fault 111,
see dealer.
ESM Communication Fault
ICON Shutdown - ICON system shifts into NEUTRAL idle if able.
Seek assistance to return to harbor. See dealer.
RPM reduction, ICON fault 149,
see dealer.
Throttle Actuator Sensor Fault
ICON Shutdown - ICON system shifts into NEUTRAL idle if able.
Return to harbor. See dealer.
RPM reduction, ICON fault 150,
see user guide.
Throttle Actuator Motion Fault
RPM reduction (See outboard’s operator’s guide for S.A.F.E.) if
throttle is unable to move to closed position. Move control lever to
NEUTRAL position. Stop outboard. Turn master power/key switch
OFF and then back to RUN position to reset system. Check throttle
linkage for obstructions to. Return to harbor. See dealer.
RPM reduction, ICON fault 151,
see dealer.
Shift Actuator Sensor Fault
ICON Shutdown - ICON system shifts into NEUTRAL idle if able.
Seek assistance to return to harbor. See dealer.
ICON fault 152, see user guide. Shift Actuator Motion Fault
Shift is unable to move to FORWARD or REVERSE gear position.
• Outboard NOT running: DO NOT shift the engines into FOR-
WARD or REVERSE while the engines are stopped. Shift ONLY
when engines are running. Turn master power/key switch OFF and
then back to RUN position to reset system.
• Outboard running: Move control lever to NEUTRAL position. Stop
outboard. Turn master power/key switch OFF and then back to
RUN position to reset system. Check shift linkage for obstructions.
If fault not corrected, return to harbor. See dealer.
