ICON SYSTEM DIAGRAM
Item Description Item Description
1 ICON Concealed Side Mount Remote Control 15 To Positive (+) 12 Volt Source
2 Control Module 16 To Accessories
3 Master Power/Key Switch 17 Buss Cable, Backbone
4 Switch Panel, START/STOP – NEUTRAL – RPM 18 Protective Covers
5 Network Power Cable, to Main Battery (12 V) 19 Electronic Servo Module (ESM)
6 Fuse, Main Network - 10 Amp 20 Engine Identity Plug
7 Fuse, Master Power/Key Switch - 3 Amp 21 To Engine CANbus Connector
8 ICON Gateway Module 22 To Engine Key Switch Connector
9 To Fuel Tank Sender(s) 23 To Engine Trim/Tilt Connector
10 To NMEA 2000 Network/Gauges 24 To Engine Solenoid
11 NMEA 2000 Network/Gauges 25 Fuse, ESM - 30 Amp
12 Buss Cable, Extension 26 Shift Actuator
13 ICON Network Hub 27 Throttle Actuator
14 Accessory Power Relay Kit
