Examples of printer configuration
6.3.2 With escape commands
1. Open the Evolis Print Center and right-click on the printer you want to congure, then on properties.
2. In the printer properties window, click on Maintenance.
3. In Command eld, type sequentially:
- Pip;192.168.2.13
- Pews;0.0.0.0,
- Penm;255.255.255.0
- Pegw;192.168.1.6
- Snetw.
- Check your conguration by typing:
· Rip;1. The result should be: 192.168.2.13 Manual
· Rews The result should be: 0.0.0.0
· Renm The result should be: 255.255.255.0
· Regw The result should be: 192.168.1.6
