Evolis Zenius - Command Sequence for Smartcard Programming

ä
The command sequence is as follows:
Sending the SIS sequence:
l A card is moved from the feeder to the contact station, and stops underneath it.
l The contact station is pushed downwards to make contact with the card.
l The printer connects the contact station to the DB-9 connector.
l The chip can be programmed via the external coupler.
Refer to the Programming Guide for the Evolis printer for more information on programming a smartcard and the
Option installation manual for conguration of the card present signal.
The Evolis product catalogue also includes printers equipped with a chip contact station and a built-in encoder. These encoders connect
to the PC via a USB interface.
