GUIDANCE FOR ELECTRICAL CONNECTIONS
We recommend that all electric work on your EazyPod Automatic
be done by a suitably qualified electrician.
ALWAYS DISCONNECT FROM MAINS BEFORE OPENING THE FRONT OF THE BOX.
For the avoidance of doubt: GREEN/YELLOW = EARTH, BROWN = LIVE, BLUE - NEUTRAL
1. To open the box, use a flat head screwdriver to
unscrew the four plastic screws on the box.
(The plastic screws remain in the lid)
3. With the box front open, familiarise yourself
with the connectors inside.
4. The fused connector block is hinged so it can
be easily opened so that you have access to the
10 Amp fuse if you need to replace this.
2. Carefully place the lid on top of the control box.
BUILT-IN
AIR PUMP
14
