4. Perform the following sequence of button presses:
Double click
ON/OFF BUTTON.
Double click
MODE 2.
Double click
MODE 2 again.
The remote should now be in the trigger setting screen
5. With ‘Set ACC Min’ highlighted, pull and hold the
ACCELERATOR TRIGGER all the way in. Press the ON/OFF
BUTTON once to set the value.
6. With ‘Set ACC Max’ highlighted, release the ACCELERATOR
TRIGGER all the way and press the ON/OFF BUTTON once
to set the value.
ON / OFF
ON / OFF
ON / OFF
MODE 2 MODE 2
PULL &
HOLD
RELEASE
x2
x1
x1
x2 x2
Acc Trigger: XXXX
Brake Trigger:XXXX
Throttle: X
Set Acc Min: XXXX
Set Acc Max: XXXX
Set Brake Min: XXXX
Set Brake Max: XXXX
return
Acc Trigger: XXXX
Brake Trigger:XXXX
Throttle: X
Set Acc Min: XXXX
Set Acc Max: XXXX
Set Brake Min: XXXX
Set Brake Max: XXXX
return
A
A
A
B
B
B
C
C
C
