Once the dimensions have been checked, attach the electrical lead to the power inlet on the back
lower right. Connect the electrical lead to the mains power, then slide the appliance into the prepared
opening.
SLIDE IN
All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting
the installation check the dimensions of both the appliance and your opening to ensure that they align
well.
Please note, if you are installing into an existing chimney breast it is imperative that the flue is
adequately blocked off.
INSET INSTALLATION - ALL MODELS
