INSET INSTALLATION - WITH SPACER - ALL MODELS
To convert your appliance to a free-standing unit you can fit an optional spacer.
Before securing the spacer, attach the electrical lead to the inlet at the back bottom corner of the
appliance. Once the spacer is fitted it will be more difficult to attach this.
Position the spacer at the back of the appliance and line up the three screw holes on both appliance
and spacer. Then screw in your three screws as shown below. The electrical lead can then slot into the
semi circular hole, allowing the appliance to sit free-standing on the floor.
INSET INSTALLATION - WALL MOUNTED - TOPAZ
All our inset models are designed to be fitted into a standard 16” wide x 22” high opening. Before starting
the installation check the dimensions of both the appliance and your opening to ensure that they align
well.
Once the measurements are confirmed, plug in the appliance and slide it into the prepared opening.
The appliance can then be screwed to the wall with the four screw holes as shown below.
