11
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 INSETS. 1INSETS. 1
FITTING THE FASCIA
MAGNETS
The following models have a fascia attached with magnets;
Argenta 16
Argenta 22
Colorado
Sphera
Kepler 22
Argenta C1
C1
C2
C3
Colorado
Topaz
SCREWED
The Brooklyn fascia is attached using screws. There are 4 screw holes located in the outside plaster kit
which line up with 4 holes in the rear of the Brooklyn fascia. Offer up the fascia, and secure in place by
screwing the fascia to the fire.
