EVS XT-3 - Rack Mount 6 U Main Frame

3.1.2. Rack Mount 6U Main Frame
Weight
Disk Configuration Weight
6U - 19 inches chassis with 6 HDD on RSAS board (fix mounted) 35 kg / 77.2 lb
6U - 19 inches chassis with 12 HDD on RSAS board (fix mounted) 37 kg / 81.6 lb
6U - 19 inches chassis with 6 HDD on hot swap rack 37 kg / 81.6 lb
6U - 19 inches chassis with 12 HDD on hot swap rack 39 kg / 86.0 lb
Dimensions
The following drawings provide the various dimensions, in mm, of the XT3 server with a
6U chassis.
Front view
Left view
