EVS XT-3 User Manual

5.7.5. Switches
Supported Switches
All switches used on the GbE networks of EVS systems need to support jumbo frames
(Ethernet frames with more than 1,500 bytes of payload).
The following models of 19-inch Gigabit switches have been validated for use with EVS
workflows:
• HP Procurve 2510G-24
• Cisco Catalyst 2960S-24TD/2960S-48TD/2960S-24TS/2960S-48TS
• Cisco Catalyst 3750X-24TS/3750X-48TS
• Arista Network 7150S-24
Comparison
The models HP Procurve 2510G-24, Cisco Catalyst 2960S-24TS and 2960S-48TS can be
used for small setups where no inter-VLAN routing is needed.
The models Cisco Catalyst 2960S-24TD and 2960S-48TD can be used for small setups
where 10G uplinks are required, but no inter-VLAN routing is needed.
On larger setups, both GbE ports of the XT3 servers or/and several ports on the SANs are
often used to increase the bandwidth or to allow redundancy. Since both GbE ports of an
XT3 server cannot be used on the same sub-network, virtual LANs need to be created. To
allow the transfer of packets between the virtual LANs, layer 3 switches are required. You
need to select a layer 3 switch that is able to route jumbo frames.
A switch of the Cisco Catalyst 3750X series should be used on larger setups as they
support jumbo frames, allow traffic to be routed between different VLANs and provide
stacking capabilities.
The following table gives an overview on the supported switches:
Model/Product
Number
RU
Gb
ports
Uplinks
JF
switching
JF
routing
Stacking Dual PS
HP Procurve
2510G-24
1 20(+4) 4x1G SFP Y N N No
Cisco Catalyst
WS-C2960S-24TD-L
1 24 2x10GIG
SFP+ or
2x1G SFP
Y N Y No
Cisco Catalyst
WS-C2960S-48TD-L
1 48 2x10GIG
SFP+ or
2x1G SFP
Y N Y No
Cisco Catalyst
WS-C2960S-24TS-L
1 24 4x1G SFP Y N Y No
78 5. Hardware Installation and Cabling
EVS Broadcast Equipment SA Issue 12.05.C- November 2014
