5.2.3. 4U Rear Panel Layout (PS2 Chassis)
Rear Panel Areas
The following drawing represents an example of a 4U rear panel available on an XT3
server.
The various areas of the rear panel are highlighted in the drawing and their respective
variants are listed in the following table along with a short description of the related
connectors.
