EVS XT-3 User Manual

4. Software Specifications
4.1. Video Specifications
Video Standards
The following table lists the video specifications both in SD and in HD format for your XT3
server.
Standard Definition High Definition
Video Formats 525i 29.97fps (NTSC)
625i 25fps (PAL)
720p 50/59.94fps
1080i 50/59.94fps
1080p 50/59.94fps (Dual Link
or 3G)
Digital Interface 10-bit 4:2:2 Serial
(ST 259:2008).
Full frame synchronizer at
input.
Dual output for PLAY
channels.
10-bit 4:2:2 Serial (ST 292-
1:2011).
Full frame synchronizer at
input.
Dual output for PLAY
channels.
Number of Channels 2, 4, 6 or 8* channels,
reversible REC/PLAY
2, 4, 6 or 8* channels,
reversible REC/PLAY
Monitoring & Down-
converters
1 CVBS per channel, with
OSD
1 SD SDI per channel, with
OSD
1 built-in down-converter per
channel, CVBS output with
OSD
1 HD SDI output per channel,
with OSD
Additional clean SD SDI
output
Reference Analog Black Burst Analog Black Burst and HD
Tri-Level Sync
Graphics Board n.a. n.a.
* From a hardware point of view, six codec modules, and therefore six channels, remain
available on the backplane. However, it is possible to increase the number of connected
record channels by connecting distinct recorders to the main and the secondary IN
connector of a codec module. Such configurations, called XREC (2 recorders per codec
module) are detailed in the Configuration manual, Supported Configurations chapter.
14 4. Software Specifications
EVS Broadcast Equipment SA Issue 12.05.C- November 2014
