EVS XT-3 User Manual

4.4.3. XF Capacities
StorageCapacity at 50Hz (PAL)
The following tables gives the time (in hours and minutes) of A/V content of a given codec
that can be stored on the XF hardware at a frame rate of 50 Hz:
Codec
Fields/
Block
1 TB 2 TB
XDCAM HD 61 44:25 88:50
Apple ProRes 422 LT 35 25:29 50:58
HD Mjpeg Standard 12 8:44 17:29
HD Mpeg-2 Intra 12 8:44 17:29
DVCPro HD 31 22:34 45:08
AVC Intra 100 30 21:51 43:42
Avid DNxHD® 120 27 19:40 39:19
Apple ProRes 422 SQ 24 17:29 34:58
Avid DNxHD® 185 18 13:07 26:13
Apple ProRes 422 HQ 16 11:39 23:18
StorageCapacity at 150Hz (PAL Super Motion 3x)
The following tables gives the time (in hours and minutes) of A/V content of a given codec
that can be stored on the XF hardware at a frame rate of 150 Hz:
Codec
Fields/
Block
1 TB 2 TB
Apple ProRes 422 LT 12 8:30 16:59
HD Mjpeg Standard 4 2:55 5:50
HD Mpeg-2 Intra 4 2:55 5:50
DVCPro HD 10 7:31 15:03
AVC Intra 100 10 7:17 14:34
Avid DNxHD® 120 9 6:33 13:07
Apple ProRes 422 SQ 8 5:50 11:39
Avid DNxHD® 185 6 4:22 8:44
Apple ProRes 422 HQ 5 3:53 7:46
42 4. Software Specifications
EVS Broadcast Equipment SA Issue 12.05.C- November 2014
