EVS XT-3 User Manual

StorageCapacity at 59.94Hz (NTSC)
The following tables gives the time (in hours and minutes) of A/V content of a given codec
that can be stored on the XF hardware at a frame rate of 59.94 Hz:
Codec
Fields/
Block
1 TB 2 TB
XDCAM HD 74 44:54 89:48
Apple ProRes 422 LT 35 21:14 42:29
HD Mjpeg Standard 14 8:30 17:00
HD Mpeg-2 Intra 14 8:30 17:00
DVCPro HD 35 21:14 42:29
AVC Intra 100 36 21:51 43:42
Avid DNxHD® 120 27 16:23 32:46
Apple ProRes 422 SQ 24 14:34 29:07
Avid DNxHD® 185 18 10:55 21:50
Apple ProRes 422 HQ 16 9:43 19:25
StorageCapacity at 180Hz (NTSC Super Motion 3x)
The following tables gives the time (in hours and minutes) of A/V content of a given codec
that can be stored on the XF hardware at a frame rate of 180 Hz:
Codec
Fields/
Block
1 TB 2 TB
Apple ProRes 422 LT 12 7:05 14:10
HD Mjpeg Standard 5 2:50 5:40
HD Mpeg-2 Intra 5 2:50 5:40
DVCPro HD 12 7:05 14:10
AVC Intra 100 12 7:17 14:34
Avid DNxHD® 120 9 5:28 10:55
Apple ProRes 422 SQ 8 4:50 9:43
Avid DNxHD® 185 6 3:38 7:17
Apple ProRes 422 HQ 5 3:14 6:28
HARDWARE TECHNICAL REFERENCE MANUAL XT3 Server 12.05
4. Software Specifications 43
